Lipari 5584-W

5G dual SIM indoor router – Fiber – Wi-Fi 6 - VoIP

The Lipari 5584-W is an innovative all-in-one 5G router, capable of reaching speeds of up to 2.5 Gbit/s over all fibre connections. Thanks to the AX3600 Wi-Fi, it guarantees high performance on wireless LANs.

Taking full advantage of Gigabit networks, both fixed and mobile, the Lipari 5584-W is perfect for high-performance, bandwidth-intensive applications. Furthermore, it supports both 5G standalone NR (SA) and non-standalone (NSA) scenarios, thus offering optimal flexibility and compatibility for modern connectivity needs.

Key factors

Always-On

Stable connections anywhere, with multiple links, transparent backup, and quality of service for uninterrupted business.

Future Proof

Protects investments with support for future technologies like 5G and/or Fiber.

ISP And Telco Ready

Designed to meet the requirements of service providers, telecom operators, carriers, and system integrators.

Power Efficiency

Minimizes energy consumption, reduces environmental impact, and lowers operational costs.

Secure By Design

Built with security in mind from the design stage, ensuring robust and secure solutions.

Smart Value

Maximizes business value with an excellent performance-to-price ratio.

LAN	GE	4	10/100/1000 Mbps Ethernet ports switch, RJ45 auto sensing connectors
LAN	Fibra	1	Port 2.5GE via SFP cages (SFP transceiver module is not included) - SFP1 label
Wi-Fi	RF		IEEE 802.11ax IEEE 802.11ac IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11a
	Frequency bands		2.4 GHz e 5 GHz simultaneous
	Throughput		1147 Mbps (2.4 GHz) 2402 Mbps (5 GHz) (theoretical maximum )
	MIMO		4 x 4
WAN	Wired Combo ETH/SFP	1	2.5GE port, via SFP cages (not included) - SFP2 label Ethernet port can serve as both LAN and WAN - eth1 label
RADIO CELLULAR	WCDMA	1	Frequencies: B1, B5, B8 Throughput : Max. 42 (DL)/Max. 5.76 (UL)
	LTE		Frequencies: LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41/42/43 Throughput: LTE-FDD: Max. 1.6 Gbps (DL) / Max. 211 Mbps (UL) () the throughput value depends on network configuration, assigned bandwidth, number of users, and RF signal condition.
	5G Sub-6 GHz		5G NR Frequencies n1/3/5/7/8/20/28/38/40/41/77/78 Throughput: 5G SA Sub-6: Max. 4.67 Gbps (DL)/Max. 1.25 Gbps (UL) () 5G NSA Sub-6: Max. 3.74 Gbps (DL)/Max. 1.46 Gbps (UL) ()
	SIM	2	nano SIM slots (Dual SIM Single ACTIVE) Type of SIM insertion: tray eject
	MIMO		DL: 4 x 4 - UL: 2 x 2 (4 external antennas via SMA connector)
VOICE	FXS	1	FXS port
CONSOLE		1	RJ45 connector

* the throughput value depends on network configuration, assigned bandwidth, number of users, and RF signal condition.

Note: The features may depend on the version and the update level of the product's firmware.

Networking

TCP-UDP IPv4, IPv6

Layer 2 features

LAN Bridging
VLAN over LAN 802.1q interfaces in Access mode, Trunk, native VLAN and Hybrid mode

Routing

Static, Policy routing

QoS

Classification of traffic based on source IP, destination IP, protocols (UDP, ICMP, TCP, etc.) and ports, and combinations thereof, application recognition, Precedence IP and DSCP
DiffServ
IP Precedence Remarking, DSCP e CoS
Shaping with guaranteed allocated band and redistribution of the exceeding band
Committed Access Rate and Multicast rate limit
Traffic prioritisation mechanisms, definition of an arbitrary number of priority classes

Security

NAT/PAT
ACLs, Stateful Firewall
SSL Tunnelling
L2TP
GRE Tunnelling with keep alive and key sequence numbering (cellular network optimization)
VPN with IPSEC/ESP or IPSEC/AH IKEv1/IKEv2

Services

DHCP client, DHCP server with antispoofing functions, DHCP Layer Discovery Protocol IEEE 802.1ab
Intelligent DNS Proxy, both local and remote
Traceroute

Management and configuration
