The Lipari 5200-IKW is a 4G LAN router, equipped with two SIM slots (mutually exclusive) to support failover and backup scenarios and 2.4 GHz Wi-Fi.
It guarantees secure communication through the creation of VPNs.
Key factors
Strength Icon
Certified
Validated for inclusion in business offering profiles and use within the networks of major telecom operators.
Strength Icon
ISP And Telco Ready
Designed to meet the requirements of service providers, telecom operators, carriers, and system integrators.
Strength Icon
Power Efficiency
Minimizes energy consumption, reduces environmental impact, and lowers operational costs.
Strength Icon
Secure By Design
Built with security in mind from the design stage, ensuring robust and secure solutions.
Strength Icon
Smart Value
Maximizes business value with an excellent performance-to-price ratio.
Strength Icon
ZTP
Zero Touch Provisioning facilitates remote management and agile configuration of the installed base.
Technical Specifications
| LAN | FE | 4 | Ethernet ports 10/100 Mbps; RJ45 connectors - with or without auto-negotiation, configurable |
|---|---|---|---|
| Wi-Fi | 1 | 802.11 b/g/n (2.4 GHz) | |
| RADIO CELLULAR | LTE |
| |
| UMTS |
| ||
| EDGE/GPRS |
| ||
| SIM | 2 |
| |
| CONSOLE | 1 | RJ45 connector |
*Throughput value depends on network configuration, assigned bandwidth, number of users, and RF signal condition.
Note: The features may depend on the version and the update level of the product's firmware.
Networking
- TCP-UDP IPv4, IPv6, ARP
Layer 2 features
- LAN Bridging
- VLAN over LAN 802.1q interface in Access mode, Trunk, native VLAN and Hybrid mode
Routing & Multicast
- Static
- BGP-4, BGP-4+
- OSPFv2
- RIPv1, RIPv2
- Policy-based routing (PBR)
- VRF Lite
- Routing redistribution and tagging
- VRRP (Virtual Routing Redundancy Protocol) with IPv4-IPv6 authentication
- IGMP v1-v2-v3, IGMP snooping, IGMP proxying
- Multicast routing with sparse-mode PIMv2 and PIMv2 dense-mode, MSDP
- IEEE 802.1d (Spanning Tree Protocol)
Security
- NAT/PAT
- ACLs, Stateful Firewall
- SSL Tunnelling
- L2TP
- GRE Tunnelling with keep alive and key sequence numbering (cellular network optimization)
- VPN with IPSec
- 3 DES Encryption
Services
- DHCP client, DHCP Relay, DHCP server with antispoofing functions, DHCP Layer Discovery Protocol IEEE 802.1ab
- Intelligent DNS Proxy, local and remote
- Traceroute
- Support of NTP Client and Server
- Easy VPN
- Dynamic DNS
Management and Configuration
- SNMP v1, SNMPv2, SNMPv3
- Telnet server with multiple simultaneous sessions
- SSH server with multiple simultaneous (SSHv2)
- IP SLA with support of: One Way Delay, Round Trip Delay, Jitter, Packet Loss
- Fault management Syslog /Trap
- RADIUS, TACACS+
- Tracking for backup management, commands and events scheduling
- Software update via TFTP and FTP
- Configuration via Command Line Interface (CLI), Text/Menu oriented and Telnet
- Configuration via HTTP WEB GUI
- Ability to maintain an arbitrary number of configurations
